Solenoid valve 2/2-way Brass/FKM (Viton) NO normaly open 230V AC thread BSPP
Model:
Normaly open
Material body:
Brass
Connection:
Thread BSPP
Material inner parts:
Brass / stainless steel
Voltage:
230V AC
Material seals:
FKM (Viton)
Operating pressure:
see tabel below.
Material pilot:
Plastic
Temperature range:
-10°C to +130°C
Protection class:
IP65
Installation position:
With upright magnets
Brand:
E-CM
Media: Compressed air, neutral gases, water, neutral low-viscosity media, other media on request
Size:
1/8"
1/4"
3/8"
1/2"
3/4"
1"
1.1/4"
1.1/2"
2"
Pressure bar:
0-13
0-13
0,5-16
0,5-16
0,5-16
0,5-16
0,5-16
0,5-16
0,5-16
kv value l/min:
3,2
3,2
64
64
108
171
313
427
684
Warning: For opening or closing, servo-controlled valves require a pressure difference between the valve inlet and valve outlet. The pressure difference is given as minimum pressure. There is a pressure compensation in the valve, resulting that no or little medium is used at the valve outlet, the valve will no longer function (it opens or closes unreliably).
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
